PRODUCT OVERVIEW

Wiring

The device is powered via 12VDC, via a 2-pin connector that may be installed in 2 dierent

options:

1. 120VAC junction box, used in conjunction with a “blue-cube” transformer, which

provides a 12VDC output to the LCD

2. Standard outlet, used in conjunction with a 12VDC power supply and LCD harness.

The Evolve LCD does not control a circuit directly. Instead, it communicates wirelessly via RF to

Evolve lighting controls, thermostats, shade and drape controllers, and more.
